| 型号:Code No. | 1LF-LK450 | 1LF-L460 | 1LF-LK550 | 1LF-LK460A | 1LF-L560 |
| 铧犁数 | 4(3+1) | 4(3+1) | 5(4+1) | 4 | 5(4+1) |
| No.of Bottom | |||||
| 单铧犁型号 | LK500栅条型 | LK500栅条型 | LK500栅条型 | LK500栅条型 | LK500栅条型 |
| Bottom No. | |||||
| 单铧工作宽度 | 33-50cm | 40-60cm | 33-50cm | 40-60cm | 40-60cm |
| Working Width Per Bottom | |||||
| 犁尖之间高度 | 182cm | 182cm | 182cm | 195cm | 195cm |
| Plough Point High | |||||
| 犁体间距 | 100cm | 120cm | 100cm | 120cm | 120cm |
| Bottom to Bottom Size | |||||
| 犁梁规格 | 140x140x12mm | 140x140x12mm | 140x140x12mm | 160x160x12mm | 160x160x12mm |
| Plough Beam Specification | |||||
| 整犁耕幅调节范围 | 132-200cm | 160-240cm | 165-250cm | 160-240cm | 200-300cm |
| Machine WNorking Width | |||||
| 重量 | 1400kg | 1480kg | 1750kg | 1800kg | 1960kg |
| (N.WNeight) | |||||
| 配套动力 160-200HP 180-220HP 180-240HP 200-240HP 220-260HP Power Required | |||||
