| 型号:Code No. | 1BYQK-400 | 1BYQK-500 | 1BYQK-600 |
| 挂接方式 Linkage Type | 半悬挂式(液压可折叠) Semi Mounted(Hydraulic Folding) | 半悬挂式(液压可折叠) Semi Mounted (Hydraulic Folding) | 半悬挂式(液压可折叠) Semi Mounted (Hydraulic Folding) |
| 工作宽幅 Working Width | 4m | 5m | 6m |
| 耕深 Working Depth | 15-20cm | 15-20cm | 15-20cm |
| 耙片直径 Disc Blade Diameter | 620mm | 620mm | 620mm |
| 耙片间距 Disc Blade Spacing | 250mm | 250mm | 250mm |
| 耙片数量 No.of Disc | 32pcs | 40pcs | 48pcs |
| 外形尺寸(长x宽x高) Overall Dimension(LxWxH) | 4500x7500x1900mm | 5500x7500x1900mm | 6500x7500x1900mm |
| 配套动力 Power Required | 180-240HP | 200-270HP | 250-320HP |
| 重量 Weight | 4700kg | 5500kg | 6500kg |
